CPU Power Connector 8 PIN +12V CPU Power Connector
Mainboard Power Connector 24 PIN Mainboard Power Connector
CPU FAN Connector 1 x CPU FAN Connector
Memory Slots 2 x DDR5 Memory Slots, Supporting 4800/OC+ Memory Speed
PCIe Slots 1 x PCIe 4.0 x16 Slot
1 x PCIe 3.0 x4 Open Slot, Supports 10Gb Ethernet Card Expansion
1 x PCIe x1 Slot
M.2 Interface 1 x PCIe 4.0 x4 Full-Speed M.2 Interface, Supports NVMe Protocol
SATA Ports 2 x SATA 3.0 Ports
USB Headers Front: 1 x USB 3.2 Gen1 Header
Front: 1 x USB 2.0 Header
Rear USB Ports 2 x USB 3.2 Gen1 Ports
4 x USB 2.0 Ports
Display Ports 1 x VGA Display Port, Supporting up to 1920x1080@60Hz
1 x HDMI™ 1.4 Display Port, Supporting up to 4096x2160@30Hz
CLR_CMOS Button CLR_CMOS Button
Audio 1 x REALTEK ALC897 Sound Card Chip
Networking 1 x Realtek RTL8125BG 2.5Gb Ethernet Port
1 x RJ45 Port
